Discover the Next Level of Printing with TM Series Printers
- 5-Color LUCIA TD Pigment Ink
- Print Speed of approximately 3.2 ppm
- Color Calibration
- Automatic Paper Detection (Type/Length/Width)
- Fat-top body design with tilt touchscreen
- EPEAT Gold Registered
This model includes a Z36 Scanner, Stand & Flat Basket
The TM Series printers redefine the possibilities of large format printing, offering enhanced productivity, efficiency, and usability compared to the previous imagePROGRAF TM & TA series. The imagePROGRAF TM-355 MFP Z36 is perfect for low-volume users in small spaces, delivering exceptional color reproduction for posters, CAD documents, signage, and more, thanks to newly formulated magenta ink and advanced color calibration. Additionally, it features robust scanning capabilities.
Key Features for Superior Performance
- Innovative Design: The TM Series introduces a sleek flat-body design and full-frontal operation for increased efficiency and comfort.
- User-Friendly Interface: The new 4.3” adjustable user interface screen provides easy access to essential information such as ink levels, sub-ink tank levels, and automatic media detection indicators, all displayed on the home screen.
- Eco-Friendly Certification: Achieving EPEAT Gold and ENERGY STAR® certification, this series is environmentally responsible, replacing EPS packaging materials with sustainable cardboard packaging.
Comprehensive Creative Workflow Software
Included with the TM Series is a suite of powerful software tools to streamline your workflow:
- PosterArtist (Online and Lite versions)
- Free Layout Plus
- Direct Print Plus
- Accounting Manager
- And more
Enhance your personal and business printing needs with the advanced features and capabilities of the TM Series printers.
Print Head
PF-06
Number of Nozzles
Matte Black: 5,120 Nozzles
Other Colors: 2,560 Nozzles per Color
Droplet Size
5 Picoliter
Ink Type
Pigment: Matte Black (MBK), Cyan (C), Magenta (M), Yellow (Y), Black (BK)
Ink Tank
Shipped with printer: MBK (130ml), BK, C, M, Y (90ml)
Replacement: MBK, BK, C, Y: PFI-320 (300 ml)/PFI-120 (130ml) and M: PFI-321 (300 ml)/PFI-121 (130 ml)
Printer RAM
Standard Memory: 128 GB (2 GB Physical Memory) Hard Disk: 500 GB Media Feed Roll Feed: One Roll, Top-loading, Front Output
Media Width
Roll Feed: 8”-36” (203.2 - 917mm)
Cut Sheet: 8”-36” (203.2 - 917mm)
Media Cutter
Automatic horizontal cutting (Rotary cutter): standard
Media Thickness
0” - 0.03” (0.07 mm - 0.8 mm)
Media Core Sizes
2” Core Standard. 2”/3” Core Roll Holder Set (RH2-35) Included
Maximum Roll Outer Diameter
5.9” (150 mm)
Media Output
Flat Stacking Basket
Printing Software Utilities
Accounting Manager, Device Management Console, Direct Print Plus, Free Layout Plus, imagePROGRAF Printer Driver for Windows®/Mac®, Media Configuration Tool, PosterArtist, Canon PRINT Inkjet Selphy
Operating System
Windows 7 (32/64-bit),
Windows 8.1 (32/64-bit),
Windows 10 (32/64-bit),
Windows 11 (64-bit), Windows Server 2008R2, 2012, 2012R2, 2016, 2019, 2022 (64-bit), Macintosh OS v10.12.6-v13x
Print Language
Printer: SGRaster, HP-GL/2, HP RTL, JPEG, PDF, CALS G4
Interface
Standard (Built-in): USB 2.0 Hi-Speed, Direct USB Thumb Drive, 10/100/ 1000Base-T/TX, Wireless LAN (IEEE 802.11 b/g/n)
Power Supply
AC 100 – 240V (50 – 60 Hz)
Power Consumption
Max: Approx. 69W Standby: Approx. 1.6W Power Off: Approx. 0.1W
Z36 SCANNER
Scan Speed
24-bit Color @ 200 dpi: 3” (Per Second)
8-bit Grayscale and Monochrome @ 200 dpi: 13” (Per Second)
Scan Modes
16.7 Million Color RGB (24-bit)
256-level Grayscale (8-bit)
Black-and-white (1-bit)
Color Space
sRGB
Maximum Resolution
1200 dpi
Scan Accuracy
+/- 0.1% : +/- 1 pixel
Maximum Scan Width
36”
Maximum Media Width
38”
Maximum Scan Length
315” (PDF/JPEG); 598” (TIFF)
Maximum Media Thickness
0.003” – 0.04” (0.07 mm – 1.0 mm)
- Printer
- Flat Stacking Basket
- Starter Ink Tanks BK/C/M/Y (90ml) MBK (130ml)
- 1 Print Head
- Maintenance Cartridge (Installed)
- 2" Roll Holder with 3” Adapters
- Installation Guide
- User Registration Card
- One Year Printer Warranty Statement
- Print Head Warranty Statement
- Call Center Notice
- Media Compatibility Flyer
- PosterArtist Web Notice Flyer
- Safety and Environmental Information
- iWR Service Terms Leaflet
- USB port (High Speed)
- Power Cable & Screw
- Gigabit Ethernet (Built-in)
