Unleash the Potential of Large Format Printing with TM Series Printers
Advanced Printing Solutions for Small Spaces
- 5-Color LUCIA TD Pigment Ink
- Print Speed of approximately 2.7 ppm
- Color Calibration
- Automatic Paper Detection (Type/Length/Width)
- Fat-top body design with tilt touchscreen
- EPEAT Gold Registered
This model includes a Stand & Catch Basket
Discover the next level of large format printing with the TM Series printers, designed to enhance productivity, efficiency, and usability compared to the previous imagePROGRAF TM & TA series. The imagePROGRAF TM-340 is ideal for entry-level users in small spaces, providing exceptional color reproduction with newly formulated magenta ink and precise color calibration. Perfect for printing posters, CAD documents, signage, and more.
User-Friendly Design for Maximum Efficiency
The redesigned imagePROGRAF TM Series prioritizes efficiency and comfort. Featuring a sleek flat-body design and full-frontal operation, these printers simplify the printing process. The new 4.3” adjustable user interface screen offers real-time updates on ink levels, sub-ink tank levels, automatic media detection, and other key settings, all easily accessible from the home screen.
Eco-Friendly and Certified Excellence
Setting new standards in eco-friendly printing, the TM Series is the first in the imagePROGRAF TM lineup to achieve EPEAT Gold registration and ENERGY STAR® certification. Additionally, these printers are transitioning to eco-friendly cardboard packaging, replacing EPS materials.
Comprehensive Creative Workflow Software
The TM Series includes a powerful suite of creative workflow software, designed to streamline your projects. Benefit from tools like PosterArtist (Online and Lite versions), Free Layout Plus, Direct Print Plus, Accounting Manager, and more, tailored to meet all your personal and business printing needs.
Print Head
PF-06
Number of Nozzles
Matte Black: 5,120 Nozzles
Other Colors: 2,560 Nozzles per Color
Droplet Size
5 Picoliter
Ink Type
Pigment: Matte Black (MBK), Cyan (C), Magenta (M), Yellow (Y), Black (BK)
Ink Tank
Shipped with printer: MBK (80 ml), BK, C, M, Y (55 ml)
Replacement: MBK, BK, C, Y: PFI-030 (55 ml) and M: PFI-031 (55 ml)
Printer RAM
2 GB
Media Width
Roll Feed: 8” - 36.1” (203.2 mm - 917 mm)
Cut Sheet: 8” - 36.1” (203.2 mm - 917 mm)
Media Cutter
Automatic horizontal cutting (Rotary cutter): standard
Media Thickness
0” - 0.03” (0.07 mm - 0.8 mm)
Media Core Sizes
2” Core Standard. 2”/3” Core Roll Holder Set (RH2-35) Optional
Maximum Roll Outer Diameter
5.9” (150 mm)
Printing Software Utilities
Accounting Manager, Device Management Console, Direct Print Plus, Free Layout Plus, imagePROGRAF Printer Driver for Windows®/Mac®, Media Configuration Tool, PosterArtist, Canon PRINT Inkjet Selphy
Operating System
Windows 7 (32/64-bit),
Windows 8.1 (32/64-bit),
Windows 10 (32/64-bit),
Windows 11 (64-bit), Windows Server 2008R2, 2012, 2012R2, 2016, 2019, 2022 (64-bit), Macintosh OS v10.12.6-v13x
Print Language
Printer: SGRaster, HP-GL/2, HP RTL, JPEG, PDF, CALS G4
Interface
Standard (Built-in): USB 2.0 Hi-Speed, 10/100/ 1000Base-T/TX,
Wireless LAN (IEEE 802.11 b/g/n)
Power Supply
AC 100 – 240V (50 – 60 Hz)
Power Consumption
Max: Approx. 65W
Standby: Approx. 1.6W
Power Off: Approx. 0.1W
Printer Dimensions (H x W x D) and Weight
(With Basket opened) 41.7” x 50.6” x 34.1”, 130.5 lbs.
- Printer
- Stand/Catch Basket
- Starter Ink Tanks BK/C/M/Y (55ml) MBK (80ml)
- 1 Print Head
- Maintenance Cartridge (Installed)
- 2" Roll Holder
- Installation Guide
- User Registration Card
- One Year Printer Warranty Statement
- Print Head Warranty Statement
- Call Center Notice
- Media Compatibility Flyer
- PosterArtist Web Notice Flyer
- Safety and Environmental Information
- iWR Service Terms Leaflet
- USB port (High Speed)
- Power Cable & Screw
- Gigabit Ethernet (Built-in)
