11 Mil Water-Resistant Synthetic Banner was developed to provide the wide-format printing industry with a truly sustainable inkjet-printable solution that incorporates the 3Rs: Reduce, Reuse, and Recycle. This non-woven polyolefin product is an integral part of ABAQA’s Environmental Impact Minimization (EIM) program, which is dedicated to providing products that decrease the environmental impact of the graphics industry.
Compatible with aqueous dye and pigment inks and HP Latex ink.
Benefits
- 100% recyclable banner
- Weatherproof solution that will not fade, tear, or rip
Applications
- Wide format banners and durable documents
- Maps, Guides, Tags, & Labels
Customers
- POP/POS retail printers
- Sign companies
- Print service providers
Material Type
100% recyclable HDPE non-woven synthetic
Gauge
11 mil
Weight
148 gsm
Whiteness
132.6% (CIE)
Opacity
96.29%
Gloss Level
2.9%
Tensile Strength
63.64 (MD) Test Method ASTM D5035
Temperature Resistance
-100F to 270F, -56C to 104C
Fungus Resistance
Yes
Flame Rating
Class A Flame Rating
Core Size
3” ID core with 2” adaptable insert
Software Settings
The coating on this product is engineered for 400% ink coverage. Optimal printer settings will vary from printer manufacturers. Recommended heater settings of 122° F (50°C) for both pre and post heaters.
Light Fastness
The fading time of inkjet ink is a direct result of the inks that you choose to use and the environment where the print is displayed. Please consult with your ink manufacturer for light fastness data.
Finishing
Synthetic Banner can be sewn, grommeted, or hemmed with Heavy Duty Banner Tape. Grommets should be placed in the hemline along the length of the banner so that the grommet is through two layers. Corner grommets should be placed where the length and width hems cross, so that the grommet is through four layers. A reinforced corner is also recommended to increase durability.
Water Resistance
To obtain a high degree of water resistance, use only pigmented ink. Allow the print to dry for 24 hours before exposing to moisture. Lamination is not required. Ink saturation over 250% can affect the waterresistant properties and show ink bleed.
Ideal Storage Conditions
70° F (21° C), 50% R.H. (a controlled environment is recommended); store in original packaging.
Optimal Service Environment
60°-80° F, 20-80% Relative Humidity.
Color
White
Ink Compatibility
Compatible with all thermal and piezo inkjet printers using water-based dye and pigment-based inks.
Shelf Life
1 year from the ship date when stored in proper conditions.
