16 Mil Water-Resistant Opaque Scrim Vinyl continues to set the standard for durability and image quality. The 16-mil scrim vinyl banner material has a blockout layer that provides 100 percent opacity. With added scratch and water resistance, a super smooth finish, and premiere color reproduction, this scrim banner is a high-quality, universal solution for spectacular, high-impact graphics designed to stand up to the test of time.
Benefits
- Photo-quality banner with exceptional water-resistance
- 100% opaque block out layer
- High white point
Applications
- Indoor / outdoor banners
- POS / POP signage
- Trade show displays
Customers
- Sign shops
- Print service providers
- Trade show display companies
Material Type
Scrim reinforced vinyl w/ blockout layer
Gauge
16 mil
Weight
490 gsm
Finish
Pressure-sensitive vinyl laminates can be applied to increase the fade and abrasion resistance of the image. Before applying the laminate, allow the image to dry for 24 hours.
Whiteness
120% (CIE)
Opacity
100%
Gloss Level
5%
RIP & Printer Media Settings
For the best and most consistent results, a profile should be created using an external color calibrator in conjunction with your RIP and color matching software. However, if these tools are not available, printers using dye ink should be set for the highest print quality and media selection should be “Photopaper”. When using UV inks, the “heavy weight coated” option should be selected. Ink coverage up to 300% is recommended.
Light Fastness
The fading time of inkjet ink is a direct result of the inks that you choose to use and the environment where the print is displayed. Please consult with your ink manufacturer for light fastness data.
Water Resistance
To obtain a high degree of water resistance, use only pigmented ink. Allow the print to dry for 24 hours before exposing to moisture. Lamination is not required. Ink saturation over 250% can affect the waterresistant properties and show ink bleed.
Optimal Service Environment
60°-86° F, 50% Relative Humidity.
Ideal Storage Conditions
70° F (21° C), 50% R.H. (a controlled environment is recommended); store in original packaging.
Color
L 90-94, a-1.0+/- 1.0, b* 2.0+/-1.0
Ink Compatibility
Compatible with all thermal and piezo inkjet printers using water-based dye and pigment-based inks.
Shelf Life
1 year from the ship date when stored in proper conditions.
