Price includes $200 instant rebate. Offer is valid through December 31, 2024.
The sleek 36" wide printer/scanner/copier for CAD, Architecture, Engineering and Corporate Graphics.
Enhance the way you work with the all-new the SureColor T5170M 36" wide MFP printer. Featuring a 36" wide printer with an integrated scanner in a sleek, ultra-small footprint up to 15% smaller than its competitors, the T5170M allows for seamless team collaboration. Engineered for productivity, the SureColor T5170M delivers A1/D-size prints in as fast as 31 seconds, supports a variety of media—including rolls and sheets—and features integrated wireless and Wi-Fi Direct® connectivity for easy printing from virtually anywhere in your home or office with a smart device4. From blueprints and technical documents to renderings and graphics, the T5170M consistently delivers durable, precise prints with Epson® PrecisionCore® MicroTFP® printhead technology and archival-quality, all-pigment-based UltraChrome® XD2 inks.
Features
- 36" wide printer with ultra-fast print speeds - A1/D-size prints in as fast as 34 seconds
- Streamline workflow with high-detail 36" wide integrated scanner - easily scan and share documents; up to 600 dpi scanner with highlight detection accurately scans annotated blueprints and drawings
- Compact, Clean Design - sleek, ultra-small design enhances workspaces
- Durable, instant-dry prints - archival-quality, all-pigment-based UltraChrome XD2 inks deliver brilliant color, crisp lines, and smudge and water-resistant prints
- Versatile Print media handling - accommodates rolls up to 36" wide and sheets up to 11" x 17" through the auto-sheet feeder
- Easy to operate - large, intuitive 4.3" LCD screen simplifies operation
-
Print from virtually anywhere in your home or office — easily print from USB thumb drives, tablets, smartphones and more with integrated wireless plus router-free Wi-Fi Direct printing
-
Extreme print quality and precision — PrecisionCore MicroTFP printhead with Precision Droplet Control for outstanding clarity; up to 2400 dpi resolution captures annotations and more with incredible accuracy
-
Outstanding productivity — change cartridges less often with high-capacity ink cartridges up to 50 ml (color) and 80 ml (Black)
-
Enterprise security features and protocol support — supports secure printing and scanning remotely and at home; secure PDFs and Internet servers
Print:
Printing Technology:
PrecisionCore MicroTFP 4-channel, drop-on-demand printhead
Maximum Print Resolution:
2400 x 1200 dpi
Print Speed:
A1/D-sized print: 31 seconds
Minimum Ink Droplet Size:
Smallest Droplet Size: 4 picoliters; Variable Droplet Technology can produce up to three different sizes per line
Nozzle Configuration:
- Black: 800 nozzles (800 nozzles x 1 channels)
- Color: 2400 nozzles (800 nozzles x 3 channels)
Ink:
Ink Type:
UltraChrome XD2 pigment ink; 4-color (C, M, Y, K)
General:
Operating Systems:
- Mac® OS X® (10.6.8 or later)9
- Windows® 10, 8.1, 7 (32-bit, 64-bit)9
Temperature:
Storage: -4 ˚ to 104 ˚F (-20 ˚ to 40 ˚C)
Humidity:
- Operating: 20–80% (no condensation)
- Operating (Recommended): 45–60% (no condensation)
- Storage: 5–85% (no condensation)
Operating Temperature:
- Operating: 50 ˚ to 95 ˚F (10 ˚ to 35 ˚C)
- Operating (Recommended): 59 ˚ to 77 ˚F (15 ˚ to 25˚C)
Dimensions:
50" x 24" x 39"
Weight:
122 lbs (56 kg)
Security:
IEEE802.1x, SNMP 3, TLS/SSL, SMTPs, POPs, FTPs, IPsec, Administrator Mode, WPA3
Safety Approvals:
USA and Canada (NRTL Certified, CSA/UL 62368-1)
Country of Origin:
Indonesia
Warranty:
Standard 1-year usually next-business day on-site repair with toll-free phone support Monday through Friday
General:
Maximum Copies: Up to 99
Reduction/Enlargement: 25% to 400%
Auto Sheet Feeder: Up to 11" x 17"
Sheet Feeder Capacity: 50 pages
Memory: 1GB (Printer) + 8GB (Scanner)
Acoustic Noise Level
- Operating: Approx. 49 dB(A)
- Sleep: Approx. 32 dB(A)
Media Type: Plain Paper, Recycled Paper, Coated Paper, Tracing Paper, Film, Blueprint, Offset Printing Paper, Carrier Sheet
Supported File Formats: JPEG, PDF (Single Page), PDF (Multi-Page), PDF/A, Encrypted PDF, TIFF
Ink Supply System:
In-box Ink Fill Volume:
- Colors (C,M,Y) 26 mL6
- Black (K) 50 mL6
Retail Ink Fill Volume:
- Colors (C,M,Y): 26 or 50 mL6
- Black (K): 50 or 80 mL6
Ink Shelf Life:
- 2 years from printed production date or 6 months after opened
- Printer is designed for use with Epson cartridges only, not third-party cartridges or ink.*
Printable Area and Accuracy:
Maximum Paper Width:
36"
Minimum Cut-sheet Size:
8.27 x 11" (1 sheet and ASF)
Minimum Paper Width:
- Roll: 13"
- Sheet: 8.27"
Line Accuracy:
±0.1% or ±0.26 mm
Maximum Printable Length:
Up to 59'8
Specifications Scanner:
Sensor:
CIS Sensor (Sheetfed)
Maximum Resolution:
Up to 600 dpi, reprint 2400 x 2100 dpi
Color and Grayscale Scan Mode (Bit Depth):
Scan to Network Folder, FTP Server, Secure FTP Server, Mail Server, Secure Mail Server, USB Memory Stick
Maximum Scan Area:
- Width: Up to 36"
- Length: Up to 8.9'
Scanning Speed:
- Up to 1.5 ips (Color)
- Up to 4.5 ips (Monochrome)
Sheet Media Handling:
Thickness:
10.2 mil
Single Sheet, Top-loading:
Up to 36" wide
Left/Right Margins:
Minimum 3 mm each
Roll Media Handling:
Single Roll-to-Roll / Top-loading Roll:
36" wide
Media Core:
2" Core Diameter: User-adjustable roll media adapters
Maximum Roll Diameter:
Up to 4.6"
Maximum Roll Weight:
6.6 lb
Media Thickness:
Up to 8.2 mil
Roll Cutting:
High-speed internal rotary cutter; auto or manual
Roll Paper Remaining:
The amount of remaining paper can be controlled from the control panel
Printer Details:
Display:
4.3" Touchscreen
Printer Language:
- ESC/P raster
- HP-GL/2, HP RTL *1
Interfaces:
SuperSpeed USB*1, Wired Ethernet 100BASE-TX /1000BASE-T, Wireless LAN IEEE802.11 b/g/n, USB memory stick, Wi-Fi Direct5
Power:
Rated Current:
1.4A
Power Consumption:
- Operating: Approx. 26 W
- Ready: Approx. 12 W
- Sleep: Approx. 2.0 W
- Power Off (Stand By): 0.2 W
Power Requirements:
- Voltage: AC 110–240 V
- Frequency: 50–60 Hz
- Current: 1.4 A
- SureColor T5170M Printer
- Full Set of Initial Ink Cartridges (CMY – 26 mL/Black – 50 mL)
- Start Here Poster
- AC Power Cable
