Price includes $1,400 instant rebate. Offer is valid through December 31, 2024.
Imagine a wide-format production photo printer engineered to achieve exceptional quality and speed with an innovative space-saving design.
We’ve rethought photographic production printing from the ground up to deliver a high-performance solution built to enhance the way you work. Introducing the SureColor® P6570E—the next evolution in photographic production printing, only from Epson.
Featuring a completely reimagined printer design, the SureColor P6570E seamlessly produces stunning prints at true production speeds. The latest from a leader in image quality, the SureColor P6570E uses 6-color UltraChrome® PRO6 Ink with Gray to produce vivid, beautiful pictures that rival comparable 8-color printers. Designed to meet your unique photo and graphic art production needs, this versatile printer offers customizable features and easy front-panel feeding and operation to deliver next-level productivity for your business.
SCP6570ESR Features
- Innovative design fits almost any workflow — unique flattop design with complete front operation and simple automatic roll loading
- Small footprint — compact design fits into small spaces and can be pushed up against a wall
- Outstanding image quality with six colors — UltraChrome PRO6 Ink with Gray produces vibrant, rich and colorful prints with smooth gradations and neutral black-and-white images that rival comparable 8-color printers
- Incredible speed and performance — produces sharp, detailed and colorful photographic prints using a reliable PrecisionCore® MicroTFP printhead, delivering remarkable print speeds
- Print on a wide range of media for various photo applications — print on a wide range of media, including photo, fine art, canvas and rigid posterboard up to 1.5 mm thick
- Seamless single-roll productivity — automatically load and unload photo and fine art med
- No assembly required — be up and printing in as little as 30 minutes; high-speed USB 3.0, Gigabit Ethernet and Wi-Fi® (2.4 GHz and 5 GHz) options to fit virtually any workflow
- Easy to use and maintain — configurable 4.3" touchscreen control panel for simple operation, automated routine maintenance and convenient user self-service for long-term operation
- Security features and IT tools — over 28 security and IT features for office or remote office locations, including hardware encryption, IC card option for user control and tracking, and a host of IT management tools
- Maximize productivity with included Epson® software suite and Epson Cloud Solution PORT — remotely manage and monitor your printer fleet from the convenience of your laptop or smart device
Printing Technology
PrecisionCore MicroTFP 6-channel drop on-demand printhead
Ink Type
UltraChrome PRO6 pigment ink; 6-ink, 6-color ink configuration: Cyan, Magenta, Yellow, Matte Black, Photo Black and Gray
Nozzle Configuration
9,600 nozzles (400 nozzles x 24 channels x 1 head)
Droplet Technology
Smallest Droplet Size: 3.5 picoliters; Variable Droplet Technology can produce up to 3 different sizes per line
Maximum Resolution
2400 x 1200 dpi
Real Time Black Ink Switching/Dedicated Photo and Matte Black channels selected automatically
Production Print Speed
Plain Paper
Draft: (1P) 1,220 sq ft/hr
Speed: (2P) 926 sq ft/hr
High Quality: (6P) 79 sq ft/hr
Premium Photo Glossy Paper
Speed: (4P) 298 sq ft/hr
Quality: (6P) 174 sq ft/hr
Max Quality: (16P) 79 sq ft/hr
Printer Language/Drivers
ESC/P Raster
Memory/Built In
4 Gig
Epson Intelligent Ink Cartridges
In-Box Cartridge Fill Volume
240 mL each color x 6 colors total
Retail Cartridge Fill Volume
150 mL, 350 mL or 700 mL each color available x 6 colors total
Ink Cartridge Shelf Life
2 years from printed production date or 6 months after opened
Printer is designed for use with Epson cartridges only, not thirdparty cartridges or ink*.
Roll Media Handling
Single Front-Loading Roll
One 10" to 24" wide
2" or 3" Core Diameter
User-adjustable roll media spindles
Roll Cutting
High-speed internal rotary cutter; auto or manual
Minimum Auto Cut Length
8.66"
Maximum Roll Diameter
Up to 6.69"
Maximum Roll Weight
15 lb
Media Thickness
0.07 mm to 0.80 mm (roll and sheet media)
Roll Paper Remaining
Printable barcode tracking system
– The amount of remaining media can be controlled and monitored from the front panel
Top/Bottom Margins (mm)
Normal: 20/15 (Premium Luster Photo Paper); Option: Top 3, 15, 20, 45/Bottom 3, 15
Left/Right Margin
3 mm each side; 0.24" total; or 0" at BorderFree® width
Integrated Take-Up Reel
Auto forward and backward; lightbased media sensor with inner and outer winding options
BorderFree Print Widths
10", 13", 14", 17", 20", 24"
Sheet Media Handling
Single Sheet, Front or Rear Loading
Up to 24" wide
Minimum Sheet Width: 8"
Maximum Sheet Width: 24"
Media Thickness
0.07 mm to 0.8 mm
Posterboard
0.8 mm to 1.5 mm
Top/Bottom Margins
3 mm/15 mm
Top/Bottom Margins with Centering On
15 mm/15 mm
Left/Right Margins
3 mm each side; 6 mm or 0.24" total; or 0" at BorderFree sizes
BorderFree Print Widths
10", 13", 14", 17", 20", 24"
Printable Area and Accuracy
Line Accuracy
±0.1% of specified length (±0.26 mm min.)
Minimum Sheet Size (Single Sheet)
8.5" x 11"
Maximum Printable Length
298'
Minimum Paper Width Roll:
10"/Sheet: 8"
User Control Panel
Articulating LCD Display
4.3" Touchscreen
Printer Interfaces
SuperSpeed USB 3.0, 100BASE-TX /1000BASE-T/IEEE 802.11 b/g/n/ac, USB memory stick, 960 GB SSD Optional
Operating Systems Supported
- Mac® OS X® 10.9.5 or later, macOS® 11 or later
Windows® 10, Windows 8.1, Windows8, Windows7, Windows Vista®, Windows XP® (32-bit/64-bit), WindowsServer® 2019/2016/2012 R2/2012/2008 R2/2008/2003 R2/2003 SP2 or later
General
Dimensions (W x D x H)
54" x 20" x 38.4" (storage and operating)
54" x 33" x 38.4" (paper basket extended)
Weight
253 lb
Acoustic Noise Level
Operating: 49.6 dBA according to ISO 7779
Temperature
Operating: 50 ˚F to 95 ˚F (10 ˚C to 35 ˚C)
Operating (Recommended): 65 ˚F to 75 ˚F (18 ˚C to 24 ˚C)
Storage: -4 ˚F to 104 ˚F (-20 ˚C to 40 ˚C)
Relative Humidity
Operating: 20% – 80% (no condensation)
Operating (Recommended): 45% – 60% (no condensation)
Storage: 5% – 85% (no condensation)
Safety Standards
USA and Canada (NRTL Certified, CSA/UL 62368-1).
Compliant with FCC Class B Requirements.
Electrical Requirements
Voltage: AC 110 V – 240 V
Frequency: 50 Hz – 60 Hz
Current: 3.4 A – 1.6 A
Power Consumption
Printing: Approx. 75 W
Ready: Approx. 32 W
Sleep: 2 W (1000Base-T Ethernet in Standby)
Power Off (Stand By): 0.3 W
Limited Warranty and Service
Standard 1-year usually nextbusiness day on-site repair with toll-free phone support Monday through Friday; Business Hours 8 a.m. – 5 p.m. PST
Country of Origin
Indonesia
- SureColor P6570E Printer
- Full Set of Initial Ink Cartridges (240 mL x 6 Cartridges)
- 1 Roll Media Adapter Installed
- Maintenance Boxes (preinstalled)
- Start Here Poster
- AC Power Cable
Note: Media is not included with the printer
